Input Voltage: 1-2S LiPO - 25.5T / 21.5T / 17.5T / 13.5T / 10.5T / 6.5T
Weight: 5.1oz / 145g
Shaft Dimensions: 3.18mm (1/8") x 15.3mm
Motor Diameter: 35.85mm / 1.40"
Motor Length: 50.25mm / 1.978"
Max Operating Temperature: 180°F / 82°C
Max RPM: 100,000
Bearing Dimensions: Front: 4x13x5mm
Rear: 1/8x3/8x5/32"
Rotor Size: 12.3mm BLACK - 25.5T
12.5mm BLUE - 21.5T / 17.5T / 13.5T / 10.5T
Rebuildable: Yes
Mounting Pattern: M3 @ 25.4mm / 1"
OFF ROAD
1:10 2WD Stock Buggy
1:10 2WD Stock Truck
1:10 2WD Stock Short Course 1:10 4WD Stock Buggy
ON ROAD
1:12 2WD Pan Car
1:10 2WD Pan Car
1:10 World GT
1:10 Formula 1
1:10 4WD Stock Touring Car
1:10 Drift
OVAL
1:10 2WD
1:10 SK Car
1:10 Stock Car
1:10 Winged Sprint
1S LiPo Classes
Features
60 Degrees Adjustable Timing Advance SPEC Racing Specific Design CNC Machined 6061-T6 Billet Aluminum Heat Sink Can Neodymium Sintered Magnet
Precision Engineered for Maximum Energy Conversion
High Purity Copper Windings Maximize Conductivity
Low Resistance, High Power Solder Tabs
Sensored System Ready
Anodized End-bell Plates Maximize Corrosion and Wear Resistance
High RPM Precision Bearings Oversized Front Bearing
Rebuild-able Design
Solder-less Sensor PCB Replacement Legal in Major Race Governing Bodies ROAR Approved
OUR QUALITY PROMISE
We guarantee our motors to be free from manufacturer defects for 180 days from date of purchase. All items are tested in a controlled environment prior to the packaging process to ensure you receive a top quality Tekin product. We strive to provide the highest grade professional components possible and we appreciate and treat every Tekin user as part of our family. We are RC enthusiasts designing and manufacturing quality products to give our fellow RC enthusiasts the best hobby experience possible.
