Features:
Specifications:
- Waterproof and dust-proof, suitable for all-weather condition races
- Small size with built-in capacitor module
- Three running modes: Fwd/Br, Fwd/Rev/Br, and Fwd/Rev fits for various vehicles (Fwd =Forward, Br=Brake, Rev=Reverse)
- Great current endurance capability
- Great built-in BEC output capacity
- Automatic throttle range calibration, easy to use
- Easy to set the ESC parameters with jumpers
- Multiple protections:
- Low voltage cut-off protection for battery
- Over-heat protection
- Throttle signal loss protection
Specifications:
- Fwd. Cont. / Peak Current: 60A/360A
- Rev. Cont. / Peak Current: 30A/180A
- Voltage Range: 2-3S Lipo or 4-9 NiMH
- Cars Applicable:1/10 Touring Car / Buggy / SCT / Monster / Crawler
- Suitable Motor: 540 or 550 motor
- For 2S LiPo or 6 cell NiMH: 540 or 550 Size Motor: ≥12T, Or RPM<30000 @7.2V
- For 3S LiPo or 9 cell NiMH: 540 or 550 Size Motor: ≥18T Or RPM< 20000 @7.2V
- Input: 4-9 Cell NiMH / 2-3 Cell LiPo
- BEC output: 5V/2A (Linear BEC)
- Resistance: Fwd 0.001Ω, Rev 0.002Ω
- PWM Frequency: 1KHz
- Dimension (without fan): 36.5x32x18mm
- Weight: 39g
- Cooling Fan: Not necessary
- Running Modes:
- Forward/Reverse/Brake
- Forward/Brake
- Forward/Reverse
